| General Info | |
|---|---|
| E-Com SKU Selector | 1/2 HP Shallow-Well Jet Pump with Pressure Tank |
| SKU | 8887259 |
| Package (L x W x H) | 21.8in x 11.9in x 24.2in |
| Weight | 37.7 lb |
| Details | |
|---|---|
| Brand Name | Burcam |
| Item Name | 1/2 HP Shallow-Well Jet Pump with Pressure Tank |
| Type | Shallow-well |
| Model # | 506127S |
| Series | Cast iron body |
| Duty Cycle | Continuous |
| Max. Flow Rate (GPH) | 710 |
| HP Rating (HP) | 1/2 |
| Motor Type | Totally enclosed fan cooled (TEFC) |
| Discharge Size (in.) | 1 |
| Suction Size (in.) | 1 |
| Connection Type | NPT |
| Current Rating (A) | (17A at start) 115V: 8/(8.5A at start) 230V: 4 |
| Voltage Rating (V AC) | 115/230 |
| Tank Capacity (gal.) | 7 |
| Flow Rate @ 5 ft (GPH) | 710 |
| Flow Rate @ 10 ft (GPH) | 630 |
| Flow Rate @ 15 ft (GPH) | 570 |
| Flow Rate @ 20 ft (GPH) | 495 |
| Flow Rate @ 25 ft (GPH) | 445 |
| Max. Discharge Height (ft) | 138 |
| Max. Pressure (PSI) | 60 |
| Max. Suction Lift (ft) | 25 |
| Discharge Pressure (PSI) | 30 to 60 |
| Pressure Gauge (PSI) | 0 to 100 |
| Shut-Off (PSI) | 60 |
| Construction | Cast iron body |
| Colour | Blue |
| Bearing Type | Stainless steel and sealed |
| Impeller Type | Glass-reinforced thermoplastic |
| Max. Temperature (°C) | 30 |
| Max. Temperature (°F) | 86 |
| Dimensions (in.) | 12L x 22W x 24H |
| Packaging (qty) | 1 |
